The Airmax PondSeries Aeration Systems are powerful enough to aerate ponds up to 8 acres and can be adapted to fit uniquely-shaped ponds. The PS10 system is excellent for smaller or regularly-shaped ponds, while the PS40 is perfect for larger and irregularly-shaped ponds. Made in the USA.

SilentAir Rocking Piston Compressor with Composite Cabinet
The heart of the Shallow Water High Pressure Series Aeration System is the SilentAir Rocking Piston Compressor, which works effectively while costing as little as $9.27/month. Integrated Manifold with Ball Valves simplifies airflow-management and vibration-reducing rubber feet ensure quiet operation. Each airline is equipped with Quick Disconnects for easy removal and storage. The entire compressor unit is protected by the Airmax Composite Cabinet, which combines weather protection with a ventilation fan and a high-density air intake filter to keep the compressor cool and dry. Includes a pre-wired electrical box and 6' power cord. An elevated base protects hardware from flood or rainwater damage. Cabinet is protected by a lifetime warranty, while compressor and electrical components have 3 year warranty.

EasySet Airline and ProAir 4 Diffuser
Air is delivered by EasySet Airline, which is resistant to rips and tears and is weighted in order to stay submerged and out of sight, to the virtually maintenance-free ProAir 4 Weighted Diffuser, which have an innovative sled design that remains submerged while maintaining an upright position. The high-efficiency, low-maintenance membrane sticks release air into the water column with the efficacy of airstones -- without all the maintenance! Each diffuser also has an integrated check valve to protect the compressor from back-pressure. Diffusers backed by 5-year warranty.

Contact us with the address of your pond or lake, and using satellite technology, we will configure an exact recommendation for you!

Why Should you Aerate Your Pond?

Aeration is an efficient, inexpensive way to significantly expand circulation and dramatically increase dissolved oxygen levels
This results in increased beneficial bacteria colonization in your pond: reducing muck, improving water quality, and lowering maintenance!
Resulting higher oxygen levels make your fish more active and energetic, and can help prevent fish death during stressful conditions

Model	Included Compressor	Max Pond Size	Max Depth	Max Flow Rate
PS10	SilentAir RP25 87R Piston Compressor (1/4HP)	1 acre	21' Deep (50' Deep with Deep Water Kit)	2.3 CFM
PS20	SilentAir RP50 87R Piston Compressor(1/2HP)	2 acres		4.7 CFM
PS40	SilentAir RP75 87R Piston Compressor (3/4HP)	3 acres		4.7 CFM
PS40	SilentAir RP75 87R Piston Compressor (3/4HP)	4 acres		5.8 CFM

SKU	UPC Code	Model	Volts	Amps	Included Diffusers	Included Airline
600820	811262015080	PS10	115	1.6	None	None*
600823	811262016629		230	0.8	None
600821	811262014830		115	1.6	1
600824	811262016636		230	0.8
600822	811262014847		115	1.6		100' x 3/8"
600825	811262016643		230	0.8		100' x 3/8"
600830	811262015097	PS20	115	4.1	None	None*
600833	811262016681		230	2.1	None
600831	811262014854		115	4.1	2
600834	811262016698		230	2.1
600832	811262014861		115	4.1		200' x 3/8"
600835	811262016704		230	2.1		200' x 3/8"
600840	811262015103	PS40	115	4.1	None	None*
600844	811262016742		230	2.1	None
600861	811262014878		115	4.1	3
600862	811262016759		230	2.1
600842	811262014885		115	4.1		300' x 3/8"
600846	811262016766		230	2.1		300' x 3/8"
600850	811262015110	PS40	115	5.3	None	None*
600856	811262016803		230	2.7	None
600865	811262014908		115	5.3	4
600866	811262016810		230	2.7
600867	811262016865		115	5.3		400' x 3/8"
600868	813166021617		230	2.7		400' x 3/8"

*Set up to use with 3/8" or 5/8" airline
