Designed to deliver high volume of steady airflow at low-pressure ranges, ALITA Linear Air Pumps are of high efficiency, low energy consumption and perform with low operation noise. With no sliding parts and oil-less components, ALITA air pump requires no lubrication and transfer air without any contamination. The super durable diaphragms last 3-5 years, and are easily and inexpensively replaced to keep the air pump always operating at its peak performance. After the diaphragm replacement, they will operate like new! Pump itself is protected by a 3 Year Warranty against manufacturing defect or poor workmanship.
- Oil-free motor provides steady airflow without risk of pollution
- Low energy consumption, long service life, and quiet operation
- Compact, solid construction is perfect for indoor or outdoor use
Mounting instructions:
The Alita high volume air pumps do not come with threaded outlet, because it is not intended to have restricted airflow. Instead, the large 5/8" outlet comes with a 5/8" I.D. rubber elbow. We encourage using this elbow to adapt to PVC, flexible PVC or to a gang valve like the Matala Hakko Heavy Duty Brass Gang Valves.
| Specifications for Aquarium Usage | |||
| Model | Output | Recommended Air Outlets | Recommended Depth |
| AL-15A | 20 Lpm | At least 20-25 | 18" Maximum |
| AL-40 | 48 Lpm | At least 50-60 | 24" Maximum |
| AL-60 | 68 Lpm | At least 65-75 | 24" Maximum |
| AL-80 | 85 Lpm | At least 80-95 | 24" Maximum |
| AL-120 | 130 Lpm | At least 125-145 | 30" Maximum |
| Specifications for Pond Use | ||||||
| Model | Rated Pressure | Performance | Power | Noise | Discharge | Weight |
| AL-6A | 1.4 psi, 10 kPa | 0.35 cfm, 10 Lpm | 13W | 27 dB | 1/8" FPT* | 5.8lb |
| AL-15A | 1.4 psi, 10 kPa | 0.5 cfm, 15 Lpm | 19W | 29 dB | 1/8" FPT* | 5.8lb |
| AL-25M | 1.4 psi, 10 kPa | 0.9 cfm, 25 Lpm | 23W | - | 1/8" FPT* | 7.7lb |
| AL-35M | 1.4 psi, 10 kPa | 1.25 cfm, 35 Lpm | 35W | - | 1/8" FPT* | 7.7lb |
| AL-40 | 2.18 psi, 15 kPa | 1.4 cfm, 40 Lpm | 46W | 36 dB | 5/8" | 12lb |
| AL-60 | 2.18 psi, 15 kPa | 2.1 cfm, 60 Lpm | 60W | 38 dB | 5/8" | 14lb |
| AL-80 | 2.18 psi, 15 kPa | 2.8 cfm, 80 Lpm | 85W | 39 dB | 5/8" | 14lb |
| AL-100 | 2.6 psi, 0.18 bar | 3.5 cfm, 100 Lpm | 120W | 41 dB | 5/8" | 18.2lb |
| AL-120 | 2.9 psi, 0.20 bar | 4.2 cfm, 120 Lpm | 124W | 42 dB | 5/8" | 18.2lb |
| AL-150 | 2.9 psi, 0.20 bar | 5.3 cfm, 150 Lpm | 160W | 44 dB | 5/8" | 22.3lb |
| AL-200 | 2.9 psi, 0.20 bar | 7.0 cfm, 200 Lpm | 261W | 45 dB | 5/8" | 22.3lb |
| AL-250E | 2.9 psi, 0.20 bar | 8.8 cfm, 250 Lpm | 295W | 46 dB | 5/8" | 22.3lb |
*AL-6A, AL-15A, AL-25M, AL-35M include 3/16" & 3/8" barb, 5/8" barb with 5mm ID
